How to Set Up a Corporate and Guest Wi-Fi Network with UniFi APs, Aruba Switches, and SonicWall Firewall

/ How to
Diagram UNIFI-SONICWALL-ARUBA (Small)

Providing secure Wi-Fi in a corporate environment often requires separating your internal LAN from guest traffic. This guide explains step-by-step how to set up corporate and guest wireless networks using Ubiquiti UniFi Access Points, an Aruba switch, and a SonicWall firewall. Guest users will have internet access but cannot access the corporate LAN.

This setup includes VLAN configuration, DHCP, firewall rules, UniFi controller configuration, and multicast/broadcast handling to ensure DHCP leases for guest clients work flawlessly.

1. Network Design and Plan

Here’s an example network layout:

NetworkVLAN IDSubnetGatewayNotes
Corporate LAN10192.168.10.0/24192.168.10.1AP management on this VLAN
Guest20192.168.20.0/24192.168.20.1Internet-only access
UniFi Controller–192.168.10.50–Management IP on LAN VLAN

Key concepts:

  • Corporate traffic uses VLAN 10 (native/untagged).

  • Guest traffic uses VLAN 20 (tagged).

  • SonicWall handles DHCP, NAT, and firewall isolation.

  • Aruba switch ports connecting APs and SonicWall are configured as trunks.

2. Configure Aruba Switch VLANs and Ports

Step 1: Create VLANs


vlan 10 name "LAN" vlan 20 name "GUEST"

Step 2: Configure trunk ports

  • AP ports: VLAN10 untagged, VLAN20 tagged

  • SonicWall port: VLAN10 untagged, VLAN20 tagged

  • Access ports for wired clients: VLAN10 untagged or VLAN20 untagged (guest network if needed)

Example commands for ArubaOS-Provisioning


interface 1/1/24 ! AP port vlan 10 untagged vlan 20 tagged no shutdown interface 1/1/23 ! SonicWall port vlan 10 untagged vlan 20 tagged no shutdown

If using ArubaOS-CX, the syntax will differ, but the logic remains the same: trunk for APs and firewall, access for end clients.

3. Configure SonicWall Firewall and DHCP

Step 1: Create a Guest Zone

  • Navigate to Network → Zones → Add Zone

  • Name: Guest

  • Type: Custom zone

Step 2: Add VLAN sub-interface X0.20

  • Parent Interface: X0 (LAN)

  • VLAN Tag: 20

  • IP: 192.168.20.1/24

  • Zone: Guest

Step 3: Configure DHCP for Guest

  • Interface: X0.20

  • Pool: 192.168.20.10 – 192.168.20.250

  • Gateway: 192.168.20.1

  • DNS: 1.1.1.1 / 8.8.8.8 (or internal DNS)

Step 4: Create NAT Policy

  • Guest network → WAN

  • Translate source to interface IP

  • Ensure outgoing internet works

Step 5: Configure Firewall Rules

  1. Deny Guest → LAN

    • Source: Guest_Net (192.168.20.0/24)

    • Destination: LAN_Net (192.168.10.0/24)

    • Service: Any

    • Action: Deny

  2. Allow Guest → WAN

    • Source: Guest_Net

    • Destination: Any

    • Services: HTTP, HTTPS, DNS, NTP, DHCP

    • Action: Allow

  3. Optional: Allow Guest → Controller for captive portal

    • Source: Guest_Net

    • Destination: Controller IP

    • Ports: 8080, 8443, 8880, 8843, UDP 3478, UDP 10001

Important: Firewall rules are top-down. Place specific allows (like controller access) before deny Guest→LAN.

4. UniFi Controller Configuration

Step 1: Create Networks

  • Corporate VLAN10: leave blank or explicitly VLAN10

  • Guest VLAN20: VLAN only, do not enable DHCP (SonicWall provides DHCP)

Step 2: Create SSIDs

  • Corporate: Corp-WiFi, VLAN10

  • Guest: Guest-WiFi, VLAN20, enable Client Isolation

Step 3: Configure Multicast/Broadcast Control (MBC)

  • Navigate to Settings → Wi-Fi → Advanced → Multicast/Broadcast Control

  • Whitelist SonicWall MAC to allow DHCP offers to reach guest clients

  • Save & apply

This step is crucial. Without whitelisting the SonicWall MAC, guest devices will not receive DHCP leases on VLAN20.

5. Testing and Verification

  1. LAN test: Connect a wired client to VLAN10, verify internet and LAN access.

  2. Guest test: Connect to Guest-WiFi

    • Confirm IP: 192.168.20.x

    • Confirm internet access

    • Confirm cannot reach LAN devices

    • Confirm guest clients cannot see each other (Client Isolation)

  3. Firewall logs: Monitor blocked and allowed traffic

  4. Optional: packet capture for debugging

6. Best Practices

  • Use WPA2/WPA3-Enterprise for corporate SSID, WPA2-PSK or captive portal for guests

  • Enable logging for guest activity

  • Consider bandwidth limits on guest network via SonicWall or UniFi

  • Keep all devices updated: UniFi APs, controller, Aruba switch, SonicWall firmware

  • Document VLAN IDs, IP ranges, and firewall rules

✅ Summary

  1. Create VLANs and trunk ports on Aruba switch

  2. Configure SonicWall: Guest Zone, VLAN sub-interface, DHCP, NAT, firewall rules

  3. Set up UniFi networks and SSIDs, enable client isolation

  4. Add SonicWall MAC to UniFi MBC whitelist to allow DHCP

  5. Test connectivity and firewall isolation

  6. Apply best practices for security and monitoring

This configuration ensures:

  • Corporate and Guest Wi-Fi are properly segmented

  • Guests get DHCP addresses and internet access

  • Guest devices cannot access corporate LAN

  • APs can efficiently handle broadcast/multicast without blocking DHCP
